ANTELA F1MWs202-EU

ANTELA Matter Smart Plug 16A 3680W Instruction Manual

Model: F1MWs202-EU | Brand: ANTELA

1. Вовед

Thank you for choosing the ANTELA Matter Smart Plug. This smart plug allows you to control your devices remotely, monitor energy consumption, and integrate with various smart home ecosystems like Apple Home, Alexa, Google Home, and SmartThings. Please read this manual carefully before use to ensure proper operation and safety.

Image 1.1: ANTELA Matter Smart Plug (Front View)

This image shows the ANTELA Matter Smart Plug, highlighting its compact design and the power button with an integrated LED indicator.

2. Информации за безбедност

За да обезбедите безбедно работење, ве молиме почитувајте ги следниве правила:

The smart plug is constructed from V0 flame-retardant materials for enhanced safety.
Не расклопувајте или менувајте го уредот.
Avoid exposing the device to water or humid environments.
Do not exceed the maximum load of 16A / 3680W.
Operate within the specified temperature range (up to 35°C).
Да се чува подалеку од дофат на деца.

3. Содржина на пакетот

Пакетот вклучува:

1 x ANTELA Matter Smart Plug
1 x Упатство за употреба (овој документ)

4. Спецификации на производот

Број на модел	F1MWs202-EU
Димензии на производот	5.5 x 5.5 x 8 cm
Тежина	110 гр
Тековен рејтинг	16 Ampпорано
Оперативен волtage	250 волти
Ватtage	3680 вати
Протокол за поврзување	Wi-Fi (само 2.4 GHz)
Контролен метод	Апликација, глас
Материјал	V0 Fire-retardant material
Оценка за меѓународна заштита	IP20
Сертификати	CE, RoHS, WEEE

Image 4.1: Smart Plug Dimensions

This image illustrates the physical dimensions of the ANTELA Smart Plug, showing its length and width for reference.

5. Упатства за поставување

5.1. Барања

Wi-Fi мрежа од 2.4 GHz: The smart plug requires a 2.4GHz Wi-Fi network for connection. 5GHz networks are not supported.
Compatible Hub: A Matter-compatible hub is required for full functionality and integration with smart home ecosystems.
- За корисниците на Apple: iOS, iPadOS 16.1 (or higher) and a hub such as Apple TV 4K (2nd or 3rd generation), HomePod, or HomePod mini.
- За корисници на Android: Android 8.1 or higher and a hub such as Samsung SmartThings Hub v3, Alexa Echo (4th generation), Google Nest Hub (2nd generation), Nest Hub Max, or Nest Wifi Pro.
Smart Life or Tuya Smart APP: Download the Smart Life or Tuya Smart application from your device's app store. Note: The Tuya Smart APP on Android currently does not support Matter.

Image 5.1: Compatible Smart Home Hubs

This image displays a selection of compatible hubs for Matter devices, including Amazon Alexa, Apple HomeKit, and Google Home devices, along with their respective operating system requirements.

5.2. Првично поставување и спарување

Приклучи се: Insert the ANTELA Smart Plug into a standard wall outlet.
Ресетирај уред: Press and hold the LED switch button on the smart plug for 5-10 seconds until the LED light starts blinking. This indicates the device is in pairing mode.
Отворете ја апликацијата: Open the Smart Life or Tuya Smart APP on your smartphone or tablet.
Додај уред: In the app, follow the instructions to add a new device. You can typically scan the QR code located on the product or manually search for the device.
Поврзете се на Wi-Fi: Изберете ја вашата Wi-Fi мрежа од 2.4 GHz и внесете ја лозинката.
Целосно спарување: Once connected, the LED light on the smart plug will stop blinking and remain solid. The device will appear in your app.
Integrate with Smart Home Ecosystem (Optional): To use with Apple Home, Alexa, Google Home, or SmartThings, follow the specific integration steps within your chosen smart home app, usually by scanning the Matter QR code again or linking accounts.

Image 5.2: Easy Setup via QR Code

This image demonstrates the quick connection process by scanning the QR code on the product using a smartphone application, showing a coffee maker plugged into the smart plug.

6. Упатства за работа

6.1. Basic ON/OFF Control

Рачна контрола: Press the physical button on the smart plug to manually turn the connected device ON or OFF.
Контрола на апликацијата: Use the Smart Life or Tuya Smart APP to remotely turn the smart plug ON or OFF from anywhere.

Image 6.1: Remote Control via App

This image shows a person using a smartphone to remotely control a lamp connected to the smart plug, illustrating the convenience of app-based control.

6.2. Мониторинг на енергија

The Smart Life APP allows you to monitor the electricity consumption of devices connected to the smart plug. You can view energy usage data hourly, daily, weekly, or monthly.

Отворете ја апликацијата Smart Life.
Select your ANTELA Smart Plug from the device list.
Navigate to the "Energy Monitor" or "Usage" section to view real-time and historical power consumption data.

Image 6.2: Energy Monitoring Interface

This image displays the energy monitoring interface within the Smart Life app, showing a graph of electricity usage over time, with a lamp во позадина.

6.3. Закажување и тајмери

Automate your devices by setting schedules and timers through the Smart Life APP.

Open the Smart Life APP and select your smart plug.
Go to the "Schedule" or "Timer" section.
Set specific times for the plug to turn ON or OFF. You can create daily, weekly, or one-time schedules.
Зачувајте ги вашите поставки.

Image 6.3: App Scheduling Interface

This image shows a user contemplating scheduling options on their smartphone, with a visual representation of setting ON/OFF times for the smart plug.

6.4. Гласовна контрола

Control your smart plug using voice commands with compatible smart assistants like Alexa, Google Assistant, and Siri (via HomeKit).

Ensure your smart plug is successfully integrated with your chosen smart home ecosystem (Apple Home, Alexa, Google Home).
Користете команди како што се:
- "Hey Siri, turn on my bedroom light."
- "Alexa, turn on my bedroom light."
- "Hey Google, turn on my bedroom light."

Image 6.4: Voice Control Example

This image illustrates voice control in action, showing speech bubbles with commands for Siri, Alexa, and Google Assistant to turn on a bedroom light connected to the smart plug.

7. Одржување

Исчистете го паметниот приклучок со сува, мека крпа. Не користете течни средства за чистење.
Ensure the plug is disconnected from the power outlet before cleaning.
Да се чува на ладно и суво место кога не се користи подолго време.

8 Смена на проблеми

Проблем	Можна причина	Решение
Паметниот приклучок не се поврзува со Wi-Fi.	Incorrect Wi-Fi band (5GHz instead of 2.4GHz), incorrect password, too far from router.	Ensure your router is broadcasting a 2.4GHz network. Verify Wi-Fi password. Move the smart plug closer to the router. Perform a reset (hold button 5-10 seconds).
Уредот не реагира на апликации/гласовни команди.	No internet connection, smart plug offline, incorrect integration with smart assistant.	Check your home internet connection. Verify the smart plug's status in the app. Re-link the smart plug with your smart assistant (Alexa, Google Home, HomeKit).
Energy monitoring shows 0 or incorrect data.	App synchronization issue, device not fully supported for power readings in certain ecosystems (e.g., Home Assistant via Matter).	Ensure you are using the Smart Life APP for energy monitoring, as specified. Some third-party integrations might have limitations. Check for app updates.
LED light not blinking during reset.	Button not held long enough, device malfunction.	Press and hold the button firmly for the full 5-10 seconds. If the issue persists, contact customer support.

9. Гаранција и поддршка

ANTELA products come with a standard manufacturer's warranty. For specific warranty details, please refer to the documentation provided with your purchase or contact your retailer.

If you encounter any issues or have questions regarding your ANTELA Matter Smart Plug, please contact our customer support team. We aim to respond to inquiries within 24 hours.

Контакт информации: Please refer to the contact details provided on the product packaging or the official ANTELA webсајт.
