1. Во текотview
The CHADWICK CW-8110 Car Horn Siren Alarm is a universal 12V anti-theft security system designed to protect your vehicle. It features multi-level safety arming, a powerful siren, and adjustable sensitivity to deter theft and unauthorized access. The system includes two remote controls for convenient operation and is designed for non-destructive installation.
2. Содржина на пакетот
Ве молиме проверете дали сите артикли се присутни во вашиот пакет:
- 1x Main Control Unit
- 1x Car Horn Siren Alarm
- 2x далечински управувачи
- 1x Wiring Harness Set
- 1x Англиски упатство за употреба
- Додатоци за монтирање (на пр., двострана лента, завртки)
Figure 2.1: All components included in the CHADWICK CW-8110 Car Alarm System package.
3. Карактеристики на производот
- Одлични перформанси: Multi-level safety arming and high reliability to prevent car theft and protect personal property.
- Универзална апликација: Compatible with various DC12V cars, suitable for electric, pneumatic, and retrofitted central locking systems.
- Висококвалитетен материјал: Изграден од издржливи материјали за долготрајни перформанси.
- Лесна инсталација: Designed for non-destructive installation, directly connecting to the battery terminals.
- 7-Level Sensitivity: Adjustable vibration sensor to customize trigger sensitivity.
- Dual Remote Controls: Two remote controls included for convenient arming and disarming.
- Loud Siren: 125 Decibels noise level for effective deterrence.
4. Информации за безбедност
- This product is designed for 12V DC car systems only. Do not connect to 24V systems.
- Installation should ideally be performed by professionals with car electrician certification. If installing yourself, ensure all connections are secure and correct to prevent damage to the vehicle or the alarm system.
- The system does not control central door lock functions or vehicle lights.
- Ensure the siren is mounted in a secure location away from excessive heat or moisture.
5. Поставување и инсталација
The CHADWICK CW-8110 is designed for non-destructive installation, primarily connecting directly to your vehicle's 12V battery. It is recommended to consult the detailed wiring diagram provided in the physical user manual for specific connections.
5.1 Basic Installation Steps:
- Mount the Siren: Securely mount the siren unit under the hood of your vehicle using the provided bracket and screws. Ensure it is in a location where sound is not obstructed and is protected from water.
- Поврзете се со батеријата: Connect the red wire from the main control unit to the positive (+) terminal of your 12V car battery. Connect the black wire to the negative (-) terminal. Ensure a 3A fuse is installed on the positive line.
- Position Main Control Unit: Place the main control unit in a discreet and secure location inside the vehicle, such as under the dashboard.
- Connect Vibration Sensor: If applicable, ensure the vibration sensor is connected to a stable and hard surface within the vehicle to accurately detect vibrations.
- Поставување антена: Position the antenna for optimal signal reception, typically suspended and not connected to metal surfaces.
Figure 5.1: General installation diagram for the CHADWICK Car Alarm System.
Figure 5.2: Non-destructive installation showing direct battery connection for the 12V system.
5.2 Installation Video Guide:
Video 5.1: An official CHADWICK video demonstrating the installation and features of the Car Horn Siren Alarm with 2 Remote Controllers.
6. Упатства за работа
The CHADWICK CW-8110 system is operated using the provided remote controls. Each remote has distinct buttons for various functions:
- Arming (Lock Button): Press the lock button once to arm the system. The alarm will beep once, indicating it has entered the armed state.
- Disarming (Unlock Button): Press the unlock button once to disarm the system. The alarm will beep twice, indicating it has exited the armed state.
- Car Search (Horn/Bell Button): Press the horn/bell button to locate your vehicle in a parking lot. The alarm will sound, and directional lights may flash (if connected and supported by vehicle).
Figure 6.1: Remote control functions for the CHADWICK Car Alarm System.
Слика 6.2: Предна страна view на далечинскиот управувач.
Слика 6.3: Назад view на далечинскиот управувач.
7. Прилагодување на чувствителноста
The CHADWICK CW-8110 features 7 levels of adjustable sensitivity for its vibration sensor. This allows you to customize how easily the alarm is triggered, preventing false alarms while ensuring adequate protection.
7.1 Adjusting Sensitivity:
- Refer to the specific instructions in your physical user manual for the exact procedure to enter sensitivity adjustment mode.
- Typically, you will use the remote control to cycle through the sensitivity levels.
- Test the alarm after each adjustment by gently bumping the vehicle to find the optimal setting for your environment.
Figure 7.1: Guidance on adjusting sensor sensitivity for optimal performance.
8. Одржување
- Батерии за далечински управувач: The remote controls use 6V CR2016*2 batteries. Replace them when the remote's range decreases or it stops responding.
- Проверка на системот: Periodically test the alarm system to ensure it is functioning correctly.
- Чистење: Keep the main control unit and siren free from dust and debris. Use a dry, soft cloth for cleaning.
9 Смена на проблеми
| Проблем | Можна причина | Решение |
|---|---|---|
| Лажните аларми се случуваат често. | Поставката за чувствителност е превисока. | Adjust the sensitivity level downwards (e.g., from 7 to 4 or lower). Ensure the vibration sensor is mounted on a stable surface. |
| Alarm does not trigger when vehicle is disturbed. | Sensitivity setting is too low or sensor is improperly mounted. | Increase the sensitivity level. Verify the vibration sensor is securely attached to a hard surface. |
| Remote control range is poor or unresponsive. | Low remote control battery or signal interference. | Replace the remote control batteries (CR2016*2). Ensure the antenna is properly positioned and not obstructed. |
| Сирената не се огласува. | Siren not connected, faulty wiring, or siren unit failure. | Check all siren connections. Verify power supply to the siren. If issues persist, contact support. |
10. Спецификации
- Main Unit Working Voltage: DC 12 ±3V
- Статичка струја: 10 mA
- Сирена: 10A, 125 Decibels
- Работна фреквенција: 433.92 MHZ
- Remote Control Working Voltage: DC 12V
- Remote Control Average Static Current: 0 mA
- Батерија за далечински управувач: 6V CR2016*2 (included)
- Тежина на ставката: 12.6 унци
- Димензии на производот: 5.04 x 3.78 x 3.27 инчи
- Компатибилни уреди: DC12V Cars
11. Гаранција и поддршка
For any questions or concerns regarding your CHADWICK CW-8110 Car Horn Siren Alarm System, please feel free to contact CHADWICK Direct customer support. Refer to your purchase documentation for specific warranty details and contact information.
