1. Вовед
Thank you for choosing the charmast CMP 5000mAh Portable Power Bank. This ultra-compact power bank is designed to provide fast and convenient charging for your compatible iPhone devices. Please read this manual carefully before use to ensure optimal performance and safety.
Image: The charmast CMP 5000mAh Portable Power Bank in white, showcasing неговиот компактен дизајн.
2. Карактеристики на производот
- Полнење со голема брзина: Equipped with 20W PD fast charging, capable of powering up an iPhone 14 from 0% to 50% in approximately 30 minutes.
- Мини големина: Weighing 0.2 pounds and measuring 3.03" x 1.38" x 0.96", its lipstick-sized design allows for easy portability in a pocket or purse.
- 18W PD брзо полнење: The power bank itself can be fully recharged in approximately 1.5 hours using a 9V-2A charger, or 3 hours with a 5V-2A charger.
- Капацитет од 5000 mAh: Provides approximately 0.65 charges for iPhone 14 Pro Max, 0.79 charges for iPhone 13, 0.9 charges for iPhone 12, 0.8 charges for iPhone 11, 0.9 charges for iPhone XR, and 6 charges for AirPods (2nd Generation).
- Partial Cellphone Case Friendly: Designed to accommodate phone cases with a thickness of less than 4mm.
3. Што има во кутијата
- 5000mAh Portable Charger (x1)
- USB-A to USB-C Cable (x1)
- Упатство за употреба (x1)
4. Поставување и првична употреба
4.1 Полнење на преносниот штекер
Before first use, fully charge your charmast power bank. Connect the provided USB-A to USB-C cable to the USB-C input port on the side of the power bank and to a compatible USB power adapter (not included). The LED indicators will show the charging status.
- За fast recharging, use a 9V-2A charger (approx. 1.5 hours).
- За standard recharging, use a 5V-2A charger (approx. 3 hours).
Image: The power bank connected to a wall adapter for recharging, highlighting the different charging times based on adapter output.
4.2 Проверка на нивото на батеријата
Притиснете го копчето за вклучување од страната на полначот за да view моменталното ниво на батеријата означено со LED светлата.
Video: An unboxing video demonstrating the contents and initial power-on of the charmast portable charger.
5. Упатства за работа
5.1 Полнење на вашиот уред
To charge your iPhone, simply plug the integrated Lightning connector of the power bank directly into your iPhone's charging port. The power bank will automatically begin charging your device. The LED indicators will illuminate to show that charging is active.
Image: Visual comparison of charging speed, demonstrating the 20W PD fast charging capability.
Image: The power bank connected to various Apple devices, highlighting its compatibility and charging efficiency.
6. Компатибилност
This power bank is compatible with iPhone models up to iPhone 14, including iPhone 14 Pro Max, iPhone 14 Pro, iPhone 14 Plus, iPhone 14, iPhone 13 Pro Max, iPhone 13 Pro, iPhone 13 Plus, iPhone 13, iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12 Plus, iPhone 12, iPhone 11 Pro Max, iPhone 11 Pro, iPhone 11 Plus, iPhone 11, iPhone XS/iPhone XR/iPhone X/iPhone 8/7/6, and AirPods (2nd and 3rd Generation), AirPods Pro (1st and 2nd Generation).
Забелешка: Not applicable for iPhone 15 series or newer models with USB-C ports unless a suitable adapter is used.
Image: A visual guide detailing compatible iPhone models and AirPods for the power bank.
6.1 Компатибилност на куќиштата
The power bank is designed to be partially case-friendly, fitting most phone cases with a thickness of less than 4mm. Cases thicker than 4mm, such as some OtterBox models, may prevent a proper connection.
Image: A visual representation of the power bank's compatibility with different phone case thicknesses.
7. Информации за безбедност
During fast charging, it is normal for both the power bank and the connected device to experience some heat. If excessive heat is observed, disconnect the device immediately. Avoid exposing the power bank to extreme temperatures, direct sunlight, or moisture. Do not disassemble or attempt to repair the device.
8. Одржување
To ensure the longevity of your power bank, store it in a cool, dry place away from direct sunlight. Clean the exterior with a soft, dry cloth. Avoid using harsh chemicals or abrasive materials. Periodically charge the power bank if it is not used for extended periods to maintain battery health.
9 Смена на проблеми
If the power bank is not charging your device:
- Осигурајте се дека самиот полнач е доволно наполнет.
- Verify that the Lightning connector is fully inserted into your device's charging port.
- Check for any obstructions or debris in the charging ports of both the power bank and your device.
- Remove any thick phone cases that might be preventing a proper connection.
If the power bank is not recharging:
- Ensure the USB-A to USB-C cable is securely connected to both the power bank's input port and the power adapter.
- Try using a different USB power adapter or wall outlet.
10. Спецификации
| Карактеристика | Детал |
|---|---|
| Димензии на производот | 1.38 x 3.03 x 0.97 инчи |
| Тежина на ставката | 4.6 унци |
| Број на модел на ставка | CMP |
| Тип на батерија | Литиум полимер |
| Капацитет на батеријата | 5000 милиониamp Hours (18.5 Wh) |
| Посебни карактеристики | Auto Shut-Off, Dust Resistant, Fast Charging, Lightweight, Pocket Size |
| Тип на конектор | Lightning (Compatible with iPhone) |
| Производител | Донг гуан Utopia-Originality Technology Co., Ltd |
| Датум прв на располагање | 12 август 2023 година |
11. Гаранција и поддршка
Your charmast power bank comes with 24-month support and 7-day/24-hour friendly customer service. If you encounter any problems or have questions, please contact us, and we will endeavor to resolve them within 24 hours.
Each item includes a unique code for verification before shipping, ensuring product authenticity.
