1. Вовед
Ви благодарам за купувањетоasing the JETBeam E26 Pocket Flashlight. This versatile device combines a powerful white light, a 365nm UV light, and a green beam, making it suitable for a wide range of applications from everyday use to specialized tasks. Please read this manual carefully before operation to ensure proper use and maintenance.
Безбедносни предупредувања
- Green Beam Safety: The output of the green beam is ≤5mW, classified as Class 3R. Do not stare into the beam or point it at aircraft or vehicles. Avoid direct eye exposure.
- Безбедност од УВ светлина: Avoid direct exposure of UV light to eyes and skin.
- Предупредување за топлина: The flashlight may become hot during prolonged use, especially in Turbo mode. Handle with care.
- Да се чува подалеку од дофат на деца.
2. Производот завршиview
Компоненти
The JETBeam E26 Pocket Flashlight is designed for portability and multi-functionality.
Image: The JETBeam E26 Pocket Flashlight in military green, shown alongside its USB-C charging cable.
Image: A detailed diagram highlighting the various components of the JETBeam E26 flashlight, including the white light, UV light, green beam, lock, revolving switch, side switch, Type-C port, indicator, and tactical switch.
Клучни карактеристики
- Тројни извори на светлина: Combines 1800 lumens white light, 365nm UV light, and a green beam in one compact device.
- Висока осветленост: White light offers 4 brightness levels (Low, Medium, High, Turbo) with a maximum output of 1800 lumens.
- Advanced UV: High-power 365nm UV light (1300mW) for professional detection tasks.
- Accurate Green Beam: 520nm green beam with ≤5mW power, suitable for pointing and surveying.
- Компактен и пренослив: Flat EDC design, 0.62” thin, 4 oz weight (battery included), with a sturdy two-way stainless steel clip.
- Издржлив и водоотпорен: Made of aviation-grade aluminum alloy, IP68 waterproof, and shatter-resistant.
- Се полни: Built-in 1700mAh Li-ion battery with USB-C charging.
- Функција на меморија: Remembers the last used brightness level for white light.
- Lockout Modes: Спречува случајно активирање.
- Ceramic Glass Breaker: Integrated for emergency situations.
Image: Illustration showing the three distinct light sources of the JETBeam E26: 1800 lumens white light, a ≤5mW green beam, and a 1300mW UV light.
Image: A hand pressing the central button to select between four brightness modes for the white light: Low (15 lm), Medium (300 lm), High (650 lm), and Turbo (1800 lm).
Image: Demonstrates the tactical tail button: a heavy press turns the flashlight on/off, while slightly pressing twice activates the strobe mode for disorienting effects.
Image: Shows practical uses for the high-power UV light (gem/antique appraisal, scorpion farming) and the accurate green beam (conference speech, site survey).
Image: Illustrates the versatility of the stainless steel clip, allowing the flashlight to be carried in side pockets, trouser pockets, attached to a backpack, or clipped to a hat brim.
Image: Highlights the built-in 1700mAh Li-ion battery, providing up to 65 hours of maximum runtime, with new IC circuit design for LED and battery protection.
Image: Shows diverse applications including meeting presentations, entertaining cats, astronomical observation, construction site surveying, ringworm detection, hotel cleanliness checking, and cat moss fungus detection.
3. Поставување
Распакување и почетна наплата
По отпакувањето, ќе ги најдете следните ставки:
- E26 flashlight (Battery Included) x 1
- Упатство за употреба x 1
- USB кабел за полнење x 1
- Ремен х 1
Before first use, it is recommended to fully charge the flashlight. Connect the included USB-C charging cable to the flashlight's Type-C port and a compatible USB power source. The power indicator will show charging status.
4. Упатства за работа
Вклучување/исклучување и избор на режим
The JETBeam E26 features two main control points: the central revolving switch/side button and the tactical tail button.
- Тактичко копче за опашка:
- Heavy Press: Turns the flashlight on or off.
- Slightly Press Twice: Activates the strobe mode (white light).
- Central Revolving Switch / Side Button:
- Ротирајте го бројчаникот: Selects between White Light, UV Light, and Green Beam modes.
- Press the Center Button (White Light Mode): Cycles through brightness levels: Low (15 lm) → Medium (300 lm) → High (650 lm) → Turbo (1800 lm). The flashlight has a memory function for the white light brightness.
- Функција за заклучување: To prevent accidental activation, refer to the diagram on the product for the lock symbol. Specific instructions for engaging/disengaging lockout are typically found near this symbol.
Light Modes and Applications
- White Light (1800 Lumens Max): Ideal for general illumination, outdoor activities, and emergency situations.
- 365nm UV Light (1300mW): Used for pet urine detection, stain identification, currency verification, resin curing, and fluorescent agent testing.
- Green Beam (≤5mW): Suitable for presentations, pointing, and site surveys.
Video: A demonstration of the JETBeam E26 UV Kunai 3-in-1 Flat EDC Flashlight, showcasing its various light modes and compact design. This video is provided by Huida Lighting, the seller.
5. Полнење
The JETBeam E26 features a built-in rechargeable Lithium-Ion battery. To charge the device:
- Пронајдете го USB-C приклучокот за полнење од страната на фенерчето.
- Connect the provided USB-C cable to the flashlight and plug the other end into a standard USB power adapter (e.g., wall charger, computer USB port, power bank).
- Индикаторската ламба за напојување ќе го покаже статусот на полнење:
- Green: 35%-100% charged
- Orange: 15%-35% charged
- Red: Less than 15% charged
- A full charge provides up to 65 hours of runtime, depending on the mode used.
Слика: Крупен план view of the USB-C charging port and the power indicator light, showing its location and function.
6. Одржување
- Чистење: Избришете го телото на фенерчето со мека, дamp крпа. Не користете абразивни средства за чистење или растворувачи.
- Водоотпорен: The E26 is IP68 waterproof. Ensure the USB-C port cover is securely closed before exposing to water. While waterproof, avoid prolonged submersion.
- Складирање: Чувајте ја батериската ламба на ладно и суво место подалеку од директна сончева светлина и екстремни температури.
- Нега на батеријата: For optimal battery life, charge the flashlight regularly, even if not in frequent use. Avoid fully discharging the battery for extended periods.
- Површинска завршница: The anti-abrasive surface finished with HA III hard anodization provides stable, tough, high pressure, corrosion, and scratch resistance.
Image: An illustration demonstrating the IPX-8 waterproof capability of the JETBeam E26 flashlight, showing it submerged in water.
Image: Details the anti-abrasive surface with HA III hard anodization, highlighting its stable, tough, high-pressure resistance, corrosion resistance, and scratch resistance properties.
7 Смена на проблеми
| Проблем | Можна причина | Решение |
|---|---|---|
| Фенерчето не се вклучува. | Low battery; Lockout mode engaged; Faulty switch. | Charge the battery; Disengage lockout mode; Contact support if switch is faulty. |
| Светлината е слаба или трепка. | Low battery; Loose connection. | Recharge the battery; Ensure all components are securely fastened. |
| Green beam or UV light not working. | Incorrect mode selected; Low battery. | Rotate the dial to the correct mode; Recharge the battery. |
| Фенерчето се загрева претерано. | Prolonged use on Turbo/High mode. | Reduce brightness level or turn off to cool down. This is normal for high-lumen flashlights. |
8. Спецификации
| Карактеристика | Детал |
|---|---|
| Модел | Е26 |
| Бела осветленост | 1800 лумени (макс) |
| Тип на извор на светлина | LED, Green Beam, UV |
| Излез на зелен зрак | ≤5mW (Класа 3R) |
| Бранова должина на УВ светлина | 365nm (1300mW) |
| Извор на енергија | Вградена литиум-јонска батерија што може да се полни |
| Капацитет на батеријата | 1700 mAh |
| Максимално траење | 65 часа |
| Порта за полнење | USB-C |
| Материјал | Анодизиран алуминиум |
| Отпорност на вода | IP68 Водоотпорен |
| Димензии на производот | 0.6" Д x 1.25" Ш x 5" В |
| Тежина на ставката | 4 ounces (battery included) |
| Максимално растојание на зракот | 689 стапки (приближно 210 метри) |
9. Гаранција и поддршка
Вид на гаранција: Доживотно
For any product inquiries, technical support, or warranty claims, please contact JETBeam customer service through your original point of purchase or visit the official JETBeam webсајт за информации за контакт.
Политика за враќање: This product typically has a 30-day refund/replacement return policy from the date of purchase, as per standard retail terms.
