Moman CP-E Motorcycle Intercom Headset User Manual

Вовед

Thank you for choosing the Moman CP-E Motorcycle Intercom Headset. This device is designed to enhance your riding experience by providing reliable communication, entertainment, and safety features. Please read this manual thoroughly before use to ensure proper operation and to maximize the product's potential.

Image: The Moman CP-E intercom main unit, showcasing its sleek design and control knob.

Содржина на пакетот

Проверете дали сите артикли наведени подолу се вклучени во вашиот пакет. Доколку некои артикли недостасуваат или се оштетени, ве молиме контактирајте ја службата за корисници.

• Moman CP-E Intercom Unit
• Headphones (Speakers)
• Microphone (Boom or Wired)
• Mounting Bracket (Clip-on)
• Adhesive Mounting Bracket
• USB кабел за полнење
• Упатство за употреба
• Accessory Kit (Velcro pads, Allen wrench, etc.)

Image: A visual representation of all components included in the Moman CP-E product box.

Поставување и инсталација

1. Полнење на уредот

Before first use, fully charge the Moman CP-E unit.

• Connect the USB charging cable to the charging port on the intercom unit.
• Connect the other end to a USB power adapter (not included) or a computer USB port.
• The indicator light will show charging status (e.g., red for charging, blue for fully charged).
• Целосното полнење обично трае приближно 2 часа. The 900mAh battery provides up to 28 hours of talk time and 300 hours of standby time.

Image: Illustration detailing the 900mAh battery, charging time, working time, and standby time.

2. Installing on Your Helmet

The Moman CP-E offers two installation methods: a clip-on bracket or an adhesive bracket. Choose the method best suited for your helmet.

Image: Step-by-step guide showing both clip-on and adhesive installation methods for the intercom unit on a helmet.

1. Изберете локација за монтирање: Select a flat area on the left side of your helmet where the intercom unit will not obstruct your vision or movement.
2. Инсталирајте звучници:
   • Remove the helmet's inner lining.
   • Attach the speakers to the ear pockets using the provided Velcro pads. Ensure they are centered over your ears for optimal sound.
   • Route the speaker wires discreetly under the lining.
3. Install Microphone:
   • For full-face helmets, use the soft-wire microphone and attach it to the inside of the chin bar with Velcro, positioning it close to your mouth.
   • For open-face helmets, use the boom microphone and attach it to the helmet lining, positioning it in front of your mouth.
4. Mount Intercom Unit:
   • Clip-on Method: Slide the metal clip between the helmet shell and the inner lining. Secure it firmly.
   • Метод на лепење: Clean the chosen area on the helmet. Peel off the protective film from the adhesive bracket and firmly press it onto the helmet for at least 30 seconds. Allow 24 hours for the adhesive to cure before attaching the intercom unit.
5. Поврзете кабли: Plug the speaker and microphone cables into the corresponding ports on the intercom unit.
6. Reinstall Lining: Carefully reinstall your helmet's inner lining, ensuring no wires are pinched.

3. Initial Pairing with Mobile Device

The Moman CP-E uses an upgraded wireless chip for quick and stable pairing.

1. Ensure the CP-E unit is turned off.
2. Press and hold the Power button (or main function button) until the indicator light flashes red and blue alternately, indicating pairing mode.
3. On your mobile device, go to Bluetooth settings and search for "Moman CP-E".
4. Select "Moman CP-E" to connect. Once paired, the indicator light will flash blue slowly.

Image: Diagram illustrating the upgraded wireless chip for faster, more stable, and low-power consumption Bluetooth connectivity.

Упатства за работа

Device Controls (Glove-Friendly Knob)

The Moman CP-E features a smart, glove-friendly knob for easy operation while riding.

Image: Close-up of the Moman CP-E unit highlighting the large, rotatable knob and its functions for music, FM radio, AI voice assistant, and phone control.

• Вклучување/исклучување: Притиснете и задржете го главното копче 3 секунди.
• Прилагодување на јачината на звукот: Rotate the knob clockwise to increase volume, counter-clockwise to decrease.
• Пушти/Паузирај музика: Кратко притиснете го главното копче.
• Следна / претходна песна: Rotate the knob quickly twice (specific gesture may vary, refer to quick start guide).
• Одговори/заврши повик: Кратко притиснете го главното копче.
• Одбијте го повикот: Притиснете и задржете го главното копче 2 секунди.
• Активирајте го гласовниот асистент (Siri/Google Assistant): Double-press the main button.
• FM радио вклучено/исклучено: Press the FM button (if available, or specific knob action).
• Change FM Station: Rotate the knob while FM radio is active.

Домофонска комуникација

The Moman CP-E supports group intercom for up to 6 riders with a range of 2000 meters, and 2 riders up to 1000 meters. It also supports universal pairing with other brands.

Image: An illustration showing multiple riders communicating via the Moman CP-E intercom system, highlighting the 2000M range for 6 riders and 1000M for 2 riders.

1. Pairing Two Units:
   • Ensure both CP-E units are off.
   • On both units, press and hold the Intercom button (or main button if it serves this function) until they enter pairing mode (e.g., flashing red/blue).
   • One unit will connect to the other automatically. The indicator lights will change to a slow blue flash.
2. Starting Intercom: After pairing, a short press of the Intercom button on either unit will initiate the intercom conversation. Another short press will end it.
3. Group Intercom (3-6 Riders):
   • Pair the first two units as described above.
   • To add a third unit, put the third unit into pairing mode. Then, on one of the already paired units, press the Intercom button twice quickly.
   • Repeat this process for additional units, pairing each new unit to the last one added to the chain.
   • Once all units are paired, any rider can initiate group communication by pressing their Intercom button.
4. Универзално спарување: The CP-E supports pairing with other brands of helmet intercom headsets. Follow the pairing instructions for the other brand's device and then initiate pairing on the CP-E.

Music Sharing & FM Radio

Enjoy your favorite tunes or stay updated with FM radio while riding. Music sharing is available for two riders.

Image: Two riders on motorcycles, sharing music through their Moman CP-E intercoms, with a music player interface overlaid.

• Репродукција на музика: Once paired with your phone, music will play through the 40mm Hi-fi speakers. Use the knob for play/pause and track control.
• Споделување музика: While two CP-E units are connected via intercom, one rider can initiate music sharing. The music will then be streamed to both headsets. (Note: Intercom mode is typically paused during music sharing and must be manually re-engaged).
• ФМ радио: Activate the FM radio function via the dedicated button or knob action. Rotate the knob to scan for stations.

Image: Two panels showing a rider using AI voice assistant (e.g., "Hey, Siri") for calls and GPS, and another rider listening to FM radio with a frequency display.

Одржување и нега

• Водоотпорен дизајн: The Moman CP-E features an IP65 waterproof rating, protecting it from rain and dust. However, avoid submerging the device in water.
• Чистење: Избришете го уредот со меко, гamp крпа. Не користете груби хемикалии или абразивни средства за чистење.
• Нега на батеријата: To prolong battery life, avoid fully discharging the battery frequently. Charge the device regularly, especially if it will be stored for extended periods.
• Складирање: Чувајте го уредот на ладно и суво место кога не го користите.

Image: An illustration demonstrating the IP65 waterproof and dustproof capabilities of the Moman CP-E intercom, showing it resistant to rain, snow, and mud.

Решавање проблеми

Спецификации

Image: Visual explanation of the HIFI stereo audio, 40mm HD speaker, DSP noise cancelling, and CVC noise reduction technologies.

Гаранција и поддршка

Moman provides customer support and warranty services for its products. For specific warranty details, please refer to the warranty card included with your product or visit the official Moman webсајт.

• Услуга за клиенти: If you encounter any issues or have questions regarding your Moman CP-E headset, please contact Moman customer support. Contact information can typically be found on the product packaging, the official Moman webстраницата или преку вашата платформа за купување.
• Побарувања за гаранција: Keep your proof of purchase for any warranty claims. Some users have reported positive experiences with Moman's warranty support for replacement parts.

За дополнителни ресурси и информации за производот, можете да ја посетите Moman Store on Amazon.
